Fabrication + Assembly
PCB fabrication and assembly on one order
Splitting the board and the build across two suppliers means every yield problem starts with an argument. Ordering both from us puts the panel design, the stack-up and the solder profile under one owner.
Combined scope
| Parameter | Scope |
|---|---|
| Fabrication | 1–20 layers; see the PCB capabilities tab for the full process window |
| Assembly | SMT, THT and mixed technology; single or double-sided |
| Panel design | Assembly panel, tooling rails and fiducials designed with the build in mind |
| Joint DFM | One review covering stack-up, impedance, footprints and assembly clearances |
| Lead time | Fabrication and assembly scheduled as one chain, typically 10–18 working days |
| Accountability | Board and build defects handled by one owner; no supplier ping-pong |
| Commercial | One quote, one invoice, one shipment, priced in USD |
What the combined order buys you
Panel built for assembly
Rails, fiducials and break-off tabs are decided by the line that will run the board, not guessed by the fab.
Surface finish matched to parts
Finish and shelf life are chosen against your fine-pitch and press-fit requirements before the board is made.
One clock
Fabrication and kitting run in parallel against the same date, instead of the board waiting for parts or vice versa.
Where it fits
New designs
First builds where nobody yet knows whether a yield issue belongs to the board or to the process.
Fine-pitch and HDI builds
Boards where pad finish, via structure and paste volume have to be agreed as one decision.
Lean purchasing teams
Programs that would rather manage one purchase order than reconcile two.
Fabrication + assembly FAQ
- Can I supply my own bare boards?
- Yes. Consigned boards are inspected on arrival; anything outside the drawing is reported before the line is scheduled.
- Who is responsible if a board fails at test?
- We are. With both stages on one order, the root cause analysis and the rework or rebuild sit with a single supplier.
- Is the combined price cheaper?
- Usually, because the panel is optimized once and only one shipment leaves China. The quote still itemizes board, parts and assembly.
- Can I get the bare-board data pack?
- Yes. Stack-up, impedance report and electrical test records for the fabricated boards are released with the shipment.
Quote board and build together
Send the Gerber and BOM once; the quote covers fabrication, parts and assembly with a single lead time.
